F4S-series

F4-series

Hydraulic fork positioner with sideshift and tilting

Robust with hydraulic tilting

Advantages

  • Built for heavy loads
  • Tilting function
  • Protected piping
  • Maximum visibility for the driver

Is constructed for tough environments with very high demands. The forks are roller-mounted using 6 rollers on each fork (4 up and 2 down). The attachment sideshifts easily and smoothly even with heavy loads. Unlike the F4 series, the F4S also has a tilt function and can tilt +/- 4 - 5 degrees. The visibility for the driver is outstanding, making work safe and secure. F4S is an excellent choice for the wood industry.

Option

Load backrestcan be added to the attachment. You can choose forks with other dimensions, other materials and coatings but also with other functions such as KOOI-reachforks® andSmartFork® with sensor technology. The attachment is also available with Carrier platsand QC6 quick-connect system.

Technical data

  • Construction: Roller suspension
  • Lifting capacity: 8000 – 16000 kg
  • Standard with: 1000 - 3000 mm
  • Fork positioning: Hydraulic
  • Side-shift: Hydraulic
  • Mounting: Integrated or HOOK-ON
  • Standard fork: 1200, 2400 mm or Carrier plates

Machine

Forklift Truck
Telescopic handler

Applications

Heavy loads
Dirty enviorments
Rugged terrain

Downloads

Product folder F4S-Series
